Description
Heatstrip Enhance delivers professional-grade infrared heating with dual control options for maximum convenience. Operate via included remote or smartphone app to adjust temperature and settings from anywhere. Engineered for efficient, targeted warmth in residential and commercial spaces, this system combines advanced heating technology with intuitive controls. Perfect for patios, garages, or indoor areas requiring supplemental heat. The app integration allows scheduling and monitoring, while the remote provides instant manual adjustments. Built for reliability and performance, Heatstrip Enhance adapts to your heating needs with precision control and modern connectivity.
Features
- Indoor/outdoor electric radiant heater.
- 2 models available X-THG2400BA (2400 Watt) and X-THG3200BA (3200 Watt)
- Remote, app plus smart home connectivity. Compatible with Google and Amazon smart home platforms. Bluetooth & WIFI
- Remote control provides 3 heat levels with adjustable timer options from 0-24 hours with the touch of a button.
- Ideal Mounting Height: 7′ 6½″ to 8′ 2½″ (2.3 m– 2.5m).
- Max Mounting Height : 9′ 2¼″ outdoors 9′ 10″ indoors (2.8m outdoors and 3m indoors)
- 3-year residential and 2-year commercial warranty.
Specifications
| MODEL | VOLTAGE (V) | POWER (Watts) | CURRENT (Amps) | DIMENSIONS (mm / in) | WEIGHT (kg / lb) | CONNECTION | HEATING AREA (m2 / ft2) |
|---|---|---|---|---|---|---|---|
| X-THG2400BA | 240 | 2400 | 10 | 920 x 187 x 76mm 36 1/4″ x 7 3/8” x 2 15/16” |
9kg 20lb |
Gang Box | 6-8m2 65-86ft2 |
| X-THG3200BA | 240 | 3200 | 13.3 | 1020 x 187 x 76mm 40 3/16” x 7 3/8” x 2 15/16” |
10kg 22lb |
Gang Box | 8-10m2 86-108ft2 |
Materials of Construction:
- Face: German Schott glass
- Casing: high temperature black coated alloy. IPX5 Rated
Voltage Nominal at 50 – 60 Hertz, Single Phase
Positioning
General recommendations for HEATSTRIP® Enhance (X-THG-BA):
- Ideal mounting height: 7′ 6½″ to 8′ 2½″ (2.3m – 2.5m) . Maximum is 9’ 2 1/4” outdoors 9′ 10″ indoors (2.8m Outdoors and 3m Indoors)
- Ideal mounting location: ceiling mounted, directly above area to be heated (e.g. above a table)
For the majority of outdoor applications, the most effective method is to spot heat a table or similar area. The diagrams provides an easy selection guide for the approximate model and quantity of heaters required to heat common residential table settings.
Selection are based on HEATSTRIP Enhance (X-THGBA) being mounted at 2.4m / 8ft from the floor in a fully enclosed undercover outdoor area. Data is based on direct overhead ceiling mounting. If the heaters are wall mounted, the radiant footprint may be reduced. The below show the approximate heating area for each model, based on both an indoor protected, outdoor enclosed and outdoor exposed location.
| MODEL | INDOOR PROTECTED (m2 / ft2) | OUTDOOR ENCLOSED (m2 / ft2) | OUTDOOR EXPOSED (m2 / ft2) |
|---|---|---|---|
| X-THG2400BA | 9m2 / 30ft2 | 6m2 / 20ft2 | 4m2 / 13ft2 |
| X-THG3200BA | 14m2 / 45ft2 | 9m2 / 30ft2 | 6m2 / 20ft2 |
Mounting
The installation of HEATSTRIP® Enhance with remote and app (X-THG-BA) is simple and easy with the standard mounting brackets supplied. For other more challenging locations there are a range of mounting options available – refer to below diagrams.
The HEATSTRIP® Enhance with remote & app control can be mounted directly to the ceiling, flush mounted into the ceiling, angled downwards on a wall, suspended on chains, poles or attached to beams and rafters. Refer to the following pages for more detailed information on each mounting option.
•Chain not included
Manuals
Heatstrip Enhance Product Manual (X-THGBA)
Heatstrip Flush Mount Manual (X-THGBA)
Heatstrip Brochure
